Chipset
Intel H110
Memory
Number of Memory Slots
2×288pin
Memory Standard
DDR4 2133
Maximum Memory Supported
32GB
Channel Supported
Dual Channel
Expansion Slots
PCI Express 3.0 x16
1 x PCI Express 3.0 x16
PCI Express x1
2 x PCIe 2.0 x1 slots
Storage Devices
SATA 6Gb/s
4 x SATA 6Gb/s
Onboard Audio
Audio Chipset
Realtek ALC887
Audio Channels
7.1 Channels
Onboard LAN
LAN Chipset
Realtek 8111H
Max LAN Speed
10/100/1000Mbps
Rear Panel Ports
PS/2
1 x PS/2 mouse port
1 x PS/2 keyboard port
Video Ports
1 x DVI-D port
1 x VGA port
RJ45
1 x RJ45
USB 3.1
2 x USB 3.1 Gen1 ports
USB 1.1/2.0
2 x USB 2.0
Audio Ports
3 Ports
Internal I/O Connectors
Onboard USB
2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
Other Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x 4-pin CPU fan connector
1 x 4-pin system fan connectors
1 x Front panel audio connector
2 x Front panel connectors
1 x TPM module connector
1 x Serial Port connector
1 x Chassis Intrusion connector
1 x Clear CMOS jumper
Physical Spec
Form Factor
Micro ATX
Dimensions (W x L)
8.9" x 6.8"
Power Pin
24 Pin
